ENVIO GRATIS A TODO CHILE80-PLUS®Standard Certified
VTC’s performance surpasses the requirements of 80 PLUS standard, achieving up to 84% efficiency at 115Vac
Corrección Activa del Factor de Potencia
High power conversion efficiency. PF value up to 99%, provides clean and reliable power.
105℃ Japanese Standby Capacitor
Highly durable and solidly reliable 105℃ Japanese Standby Capacitors
120mm Extreme Temperature Control
Using COUGAR’s exclusive 120mm silent fan, the advanced frame increase the concentration of air-flow and its fan curvature has been fine-tuned to reduce vibration at any loads, helping you enjoy a quieter gaming experience.
Massive Single 12V DC Output Ready for 4K gaming!
Solid performance for high-end graphics Systems capable of delivering 4K graphics for your games!
Comparison based on VTC600’s performance data.
Características
High Efficiency That Surpasses The 80 PLUS Standard’s Requirements
Up to 84% efficiency: keep your electricity bill under control.
Ultra-Stable Voltage Output
Enhanced layout design for solid performance during gaming sessions.
105°C Japanese Standby Capacitors
Reliable and durable components that extend the PSU’s useful life.
Compatible With The Latest PC Technology
Supports the ATX12V standard’s requirements and allows you to use the newest multi-core CPUs.
Super-silent 120mm fan with Automatic Thermal Control
Minimal noise, maximum safety!
Integrated Air Inlet Design
A highly aerodynamical design created to further reduce noise.
Massive Single 12V DC Output: 4K Compatible
Extreme stability for the most powerful graphics cards.
Supports Multi-GPU Technology: PCI Express 3.0
Supports PCI Express 3.0 next-generation graphic card with 8(6+2)pin PCI-E connector
Active Power Factor Correction (Active PFC)
A PF value up to 99% provides a clean and reliable power output.
Full Protections with OCP, SCP, OVP, UVP and OPP
Especificaciones
| Nombre del modelo | Entrada AC | Salida DC | |||||
| +3.3V | +5V | +12V | -12V | +5Vsb | Total | ||
| VTC400 |
100-240V~ 50-60Hz 6/A |
16A | 16A | 30A | 0.3A | 3A | 400W |
| 120W | 360W | ||||||
| VTC500 |
100-240V~ 50-60Hz 8/4A |
16A | 17A | 40A | 0.3A | 3A | 500W |
| 120W | 480W | ||||||
| VTC600 |
100-240V~ 50-60Hz 10/5A |
18A | 18A | 48A | 0.3A | 3A | 600W |
| 120W | 576W | ||||||
| Connector | Principal | CPU | Periféricos | S-ATA | PCI-E |
| Pin | 24(20+4) Pins | 8(4+4) Pins 8 Pins |
4 Pins | 5 Pins | 8(6+2) Pins |
| VTC400 | 1 | 1 | 2 | 4 | 1 |
| VTC500 | 1 | 1 | 2 | 5 | 2 |
| VTC600 | 1 | 1 | 2 | 6 | 2 |
Protección
OCP (Overcurrent Protection)
Si la corriente en una línea es más alta de lo establecido, la fuente se apagará automáticamente.
UVP (Under Voltage Protection)
Si el voltaje baja por debajo del valor tolerado en una línea, la fuente se apagará automáticamente.
OVP (Over Voltage Protection)
Si los voltajes suben por encima de los valores tolerados en una línea, la PSU se apagará automáticamente.
SCP (Short-Circuit Protection)
En caso de cortocircuito, esta característica evita daños a los componentes principales de la fuente de alimentación y de tu sistema.
OPP (Over Power Protection)
Si el sistema está sobredimensionado y requiere de la fuente más energía de la que ésta puede proporcionar, esta protección será activada.
